Description of the Company
Founded in 1899 and steeped in tradition. From 1984, we have established ourselves as a global player in vacuum and cryogenic engineering through quality, innovation and perfection.
PRODUCT RANGE
| Vacuum super-insulated transfer pipelines | Rigid and flexible Various nominal diameters Flanged connections or welded sleeves |
| Valves | Manually operated Pneumatically driven Bellow-sealed |
| Vacuum-insulated components | Phase separators Cold traps & subcoolers Cryogenic boxes and apparatus |
| Manufacturing standards and certificates | ASME B31.3 PED 97/23 ISO 9001:2015 |
EXPERTISE
Vacuum super-insulated pipelines
We produce vacuum-insulated pipe systems necessary for the transport of cryogenic liquefied gases – nitrogen, oxygen, argon, helium and hydrogen.
The equalization of the contraction between the vacuum jacket and the inner medium-conveying pipe is done by installing expansion bellows.
To reduce heat ingress, low-loss supports are used between the outer and inner pipe.
Pipeline parts are coupled by means of flanged connections or welded sleeves.
A combined evacuation and safety valve is positioned in every vacuum space. It allows the connection of a vacuum lock with pump and protects the outer pipe against excess pressure. Inner and outer pipes are subjected to a helium leakage test during production and before delivery.
To maintain the insulation vacuum, active adsorption materials are installed in the medium-conveying pipe.
Applications
- LNG industry
- Cryogenic air separation
- Food industry
- Aerospace technology
- Medical technology
- Research and development
Recent developments
In 2018 we successfully completed our to this date largest LNG project with 12 kilometers of DN 600 pipes.
